PM Vsd Screw Air Compressor​

The JX-100APMX is a single-stage screw air compressor that delivers the greatest reliability even for critical applications with minimal emission levels required for exhausting oil of not more than 3 parts per million. The Genset is designed to run on a rated power output of 75 HP (55 kW) and has the capability of developing 3000 RPM speed. The dimensions of the compressor are 1750 x 1240 x 1600mm and it weighs 1096kg proving that this compressor is robust throughout construction for various industries.

• High Exhaust Pressure: Capable of electric power operations at 0.8 MPa, versatile for most pneumatic operations.
• Substantial Exhaust Volume: It has an air delivery rate of 12.2 m³/min compatible with all sorts of tools and equipment.
• Air-Cooled System: Described as suitable for continuously performing in clients’ premises without overheating in the process of high temperatures.
• Low Noise Operation: Has a maximum noise emission standard of ≤70 dB(a) which makes it suitable for use in areas with sensitive hearing.
• Robust and Durable Design: Designed to operate at protection level IP23 along with insulation level F for better performance.

• Screw Compression Mechanism: It is used for efficient and effective performance in compressor air applications with low energy losses.
• Cooling System: The air-cooled design is efficient in controlling the operating temperatures, and at the same time the viability of the unit is well enhanced.
• Lubrication System: Having a lubricant capacitance of seventy liters, the appropriate grade of lubricant used should be 46#.
• Filters: Provides for the all-important task of minimizing the oil content in the exhaust and protecting components within the engine from detrimental particles.
• Drive System: Direct connection technology for power transmission from the motor to the compressor is incorporated within the product.

• Temperature Monitoring: It is also important to ensure that the ambient temperature does not exceed the maximum set limit of 46 degrees Celsius to avoid determined levels of heat.
• Routine Maintenance: Quite often check the oil level and replenish it if necessary, also replace filters, and do certain adjustments for the proper functioning.
• Electrical Supply Compatibility: Check that the power supply matches the compressor requirement of either 380V/50Hz in order to avoid some problems occurring.
• Noise Level Monitoring: Cross-check noise levels from time to time in order to adhere to regulations; especially in quiet areas.

We conducted in-depth market research and longtime communication with our loyal customers to find out the problems and solve problems, then developed this energy-efficient JX-100APMX-100HP/75KW permanent magnet frequency conversion screw air compressor through continuous technological innovation. In the R&D process of product design, prototyping, performance testing, and repeated optimization, every step is executed in strict accordance with international standards to ensure that each product meets the requirements of high standard industrial applications. With a strong R&D team and advanced production lines, we use the latest technology and materials to provide users with high-quality, high-performance air compressor products.
